VBO105-18NO7
RoHS
RoHS compliant
RoHS compliantPackage PWS-C
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 1.8KV 107A 4-Pin PWS-C
PDF
/
Inventory: 4661
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 50mm
Length 67mm
Height 31mm
Technical
Voltage - Peak Reverse (Max) 1.8kV
Peak Non-Repetitive Surge Current 1.65kA
Number of Phases 1
Forward Voltage 1.6V
Current - Average Rectified (Io) 107A
Max Surge Current 1.5kA
Max Reverse Leakage Current 300μA
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.6V @ 150A
Current - Reverse Leakage @ Vr 300μA @ 1800V
Diode Type Single Phase
Number of Elements 1
Qualification Status Not Qualified
Base Part Number VBO105
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Technology Standard
Subcategory Bridge Rectifier Diodes
Additional Feature UL RECOGNIZED
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2003
Packaging Bulk
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case PWS-C
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
