FBE22-06N1
RoHS
RoHS compliant
RoHS compliantPackage i4-Pac?-5
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Diode Rectifier Bridge Single 600V 20A 4-Pin ISOPLUS I4-PAC Tube
PDF
/
Buying Options
Total Price: USD $12.72
Unit Price: USD $12.716
≥1 USD $12.716
≥10 USD $10.295648
≥100 USD $9.690032
≥500 USD $8.781608
≥1000 USD $8.05486
Inventory: 230
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 32 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case i4-Pac?-5
Number of Pins 4
Weight 6.500007g
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tube
Published 2008
Series HiPerFRED2?
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature HIGH RELIABILITY
Subcategory Bridge Rectifier Diodes
Technology Standard
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 5
JESD-30 Code R-PSIP-T5
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 35W
Diode Type Single Phase
Current - Reverse Leakage @ Vr 60μA @ 600V
Voltage - Forward (Vf) (Max) @ If 2.13V @ 11A
Case Connection ISOLATED
Max Surge Current 40A
Breakdown Voltage 600V
Forward Voltage 2V
Average Rectified Current 20A
Number of Phases 1
Peak Reverse Current 60μA
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Non-Repetitive Surge Current 50A
Dimensions
Height 20.88mm
Length 19.91mm
Width 5.03mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
