GBU8G
RoHS
RoHS compliant
RoHS compliantPackage 4-SIP, GBU
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Bulk Through Hole Single Phase Standard Bridge Rectifier 1.1V @ 8A 8A 400V 80mOhm
PDF
/
Buying Options
Total Price: USD $1.94
Unit Price: USD $1.9448
≥1 USD $1.9448
≥10 USD $1.61876
≥100 USD $1.288232
≥500 USD $1.090056
≥1000 USD $0.924906
≥3000 USD $0.878662
Inventory: 224
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status PRODUCTION (Last Updated: 6 months ago)
Physical
Mount Surface Mount, Through Hole
Mounting Type Through Hole
Package / Case 4-SIP, GBU
Number of Pins 4
Supplier Device Package GBU
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2010
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Pitch 600μm
Technology Standard
Orientation Right Angle
Number of Contacts 31
Contact Resistance 80mOhm
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5μA @ 400V
Voltage - Forward (Vf) (Max) @ If 1.1V @ 8A
Forward Current 8A
Max Reverse Leakage Current 5μA
Max Surge Current 200A
Current - Average Rectified (Io) 8A
Peak Reverse Current 5A
Max Repetitive Reverse Voltage (Vrrm) 400V
Voltage - Peak Reverse (Max) 400V
Compliance
RoHS Status RoHS Compliant
