GBPC35005
RoHS
RoHS compliant
RoHS compliantPackage 4-Square, GBPC
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
Tray QC Terminal Single Phase Single Bridge Rectifier 1.1V @ 17.5A 5muA @ 50V 1.1V -65C~150C TJ
PDF
/
Inventory: 2438
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 28.8mm
Length 28.8mm
Height 8mm
Technical
Peak Non-Repetitive Surge Current 400A
Max Repetitive Reverse Voltage (Vrrm) 50V
Peak Reverse Current 5μA
Number of Phases 1
Forward Voltage 1.1V
Max Surge Current 400A
Max Reverse Leakage Current 5μA
Forward Current 35A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.1V @ 17.5A
Current - Reverse Leakage @ Vr 5μA @ 50V
Diode Type Single Phase
Element Configuration Single
Number of Elements 1
Pin Count 4
Base Part Number GBPC35005
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 35A
Peak Reflow Temperature (Cel) 260
Terminal Form SOLDER LUG
Terminal Position UPPER
Technology Standard
Subcategory Bridge Rectifier Diodes
Additional Feature UL RECOGNIZED, LOW POWER LOSS
Terminal Finish Silver (Ag)
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Tray
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case 4-Square, GBPC
Mounting Type QC Terminal
Mount Screw
