GBPC5004W-G
RoHS
RoHS compliant
RoHS compliantPackage 4-Square, GBPC-W
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
BRIDGE RECT 1P 400V 50A GBPC-W
PDF
/
Buying Options
Total Price: USD $8.34
Unit Price: USD $8.338228
≥1 USD $8.338228
≥200 USD $3.326889
≥500 USD $3.216605
≥1000 USD $3.161463
Inventory: 1164
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 4-Square, GBPC-W
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Additional Feature UL RECOGNIZED
HTS Code 8541.10.00.80
Subcategory Bridge Rectifier Diodes
Technology Standard
Terminal Position UPPER
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code S-XUFM-W4
Number of Elements 4
Configuration BRIDGE, 4 ELEMENTS
Breakdown Voltage-Min 400V
Voltage - Peak Reverse (Max) 400V
Non-rep Pk Forward Current-Max 450A
Number of Phases 1
Current - Average Rectified (Io) 50A
Output Current-Max 50A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 1.1V @ 25A
Current - Reverse Leakage @ Vr 10μA @ 400V
Diode Type Single Phase
Compliance
RoHS Status ROHS3 Compliant
