CDBHM2100L-HF
RoHS
RoHS compliant
RoHS compliantPackage TO-269AA, 4-BESOP
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
CDBHM2100L-HF; Schottky Diode Bridge Recifier; 100V; 4-Pin MBS-2
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.18815
≥1 USD $0.18815
≥10 USD $0.1775
≥100 USD $0.16746
≥500 USD $0.15798
≥1000 USD $0.14904
≥3000 USD $0.1406
Inventory: 28897
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-269AA, 4-BESOP
Number of Pins 2
Technical
Operating Temperature -55°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2011
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8541.10.00.80
Subcategory Bridge Rectifier Diodes
Technology Schottky
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number CDBHM2100
Number of Elements 4
Configuration BRIDGE, 4 ELEMENTS
Diode Type Single Phase
Current - Reverse Leakage @ Vr 1mA @ 100V
Voltage - Forward (Vf) (Max) @ If 850mV @ 2A
Max Surge Current 50A
Output Current-Max 2A
Current - Average Rectified (Io) 2A
Voltage - Peak Reverse (Max) 100V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
