CBR1-D020 image
Favorite
CBR1-D020 image
Favorite
RoHS
/
Package DIP
Category Discrete Semiconductor Products / Diodes - Bridge Rectifiers
Description
PDF
/
Inventory: 2281
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount Through Hole
Package / Case DIP
Diode Element Material SILICON

Technical

Published 2016
JESD-609 Code e0
Pbfree Code no
Part Status Active
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8541.10.00.80
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
Qualification Status Not Qualified
Operating Temperature (Max) 150°C
Operating Temperature (Min) -65°C
Number of Elements 4
Configuration BRIDGE, 4 ELEMENTS
Diode Type BRIDGE RECTIFIER DIODE
Output Current-Max 1A
Number of Phases 1
Rep Pk Reverse Voltage-Max 200V
Non-rep Pk Forward Current-Max 50A
Forward Voltage-Max 1.1V
Reverse Current-Max 10μA
Breakdown Voltage-Min 200V
Reverse Test Voltage 200V

Compliance

RoHS Status RoHS Compliant
