ISO7821DW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
Digital Isolators 5.7kVRMS Reinforced Dual100Mbps 16-SOIC
PDF
/
Buying Options
Total Price: USD $5.94
Unit Price: USD $5.94
≥1 USD $5.94
≥10 USD $5.3636
≥100 USD $5.11456
≥500 USD $4.44085
≥1000 USD $4.241257
≥3000 USD $3.867046
Inventory: 285
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (PWD) 4.6 ns
Isolated Power No
Inputs - Side 1/Side 2 1/1
Common Mode Transient Immunity (Min) 100kV/μs
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.4ns 2.4ns
Data Rate 100Mbps
Turn On Delay Time 11 ns
Propagation Delay 16 ns
Operating Supply Current 10mA
Number of Channels 2
Voltage - Isolation 5700Vrms
Base Part Number ISO7821
Supply Voltage 2.5V
Number of Functions 2
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology Capacitive Coupling
Max Power Dissipation 100mW
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 665.986997mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
Alternative Model
