ISO7820LLDWR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description DGTL ISO 5.7KV GEN PURP 16SOIC
PDF
/
Buying Options
Total Price: USD $7.16
Unit Price: USD $7.1632
≥1 USD $7.1632
≥10 USD $6.47416
≥100 USD $6.173024
≥500 USD $5.359992
≥1000 USD $5.119136
≥3000 USD $4.66745
Inventory: 1698
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 16

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology Capacitive Coupling
Voltage - Supply 2.25V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Base Part Number ISO7820
Voltage - Isolation 5700Vrms
Supply Voltage-Max (Vsup) 5.5V
Number of Channels 2
Data Rate 100Mbps
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 25ns, 25ns
Common Mode Transient Immunity (Min) 100kV/μs
Inputs - Side 1/Side 2 2/0
Isolated Power No
Pulse Width Distortion (Max) 4.5ns

Dimensions

Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
