ISO7760FDWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
16-SOIC (0.295 7.50mm Width) 6 6/0 General Purpose Digital Isolator 85kV/mus 5000Vrms 100Mbps -55C~125C
PDF
/
Buying Options
Total Price: USD $4.18
Unit Price: USD $4.18
≥1 USD $4.18
≥10 USD $3.75672
≥100 USD $3.55168
≥500 USD $3.078064
≥1000 USD $2.920227
≥3000 USD $2.620323
Inventory: 11448
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (Max) 4.9ns
Isolated Power No
Inputs - Side 1/Side 2 6/0
Common Mode Transient Immunity (Min) 85kV/μs
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 1.1ns 1.4ns
Data Rate 100Mbps
Number of Channels 6
Voltage - Isolation 5000Vrms
Base Part Number ISO7760
Terminal Pitch 1.27mm
Supply Voltage 2.5V
Number of Functions 6
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology Capacitive Coupling
Additional Feature ALSO REQUIRED VCC2 2.25-5.5V SUPPLY; ALSO OPERATE WITH 3.3V AND 5V SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 8 Weeks
