ISO7742FDW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 5KV 4CH GEN PURP 16SOIC
PDF
/
Buying Options
Total Price: USD $3.64
Unit Price: USD $3.6432
≥1 USD $3.6432
≥10 USD $3.27448
≥100 USD $3.09562
≥500 USD $2.6829
≥1000 USD $2.545338
≥3000 USD $2.283934
Inventory: 436
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (Max) 4.9ns
Isolated Power No
Inputs - Side 1/Side 2 2/2
Common Mode Transient Immunity (Min) 85kV/μs
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.4ns 2.4ns
Data Rate 100Mbps
Number of Channels 4
Voltage - Isolation 5000Vrms
Base Part Number ISO7742
Terminal Pitch 1.27mm
Supply Voltage 2.5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology Capacitive Coupling
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
