ISO7741FEDWRQ1
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
16-SOIC (0.295 7.50mm Width) 4 3/1 General Purpose Digital Isolator 85kV/mus 5000Vrms 100Mbps -40C~150C
PDF
/
Buying Options
Total Price: USD $3.25
Unit Price: USD $3.2472
≥1 USD $3.2472
≥10 USD $2.9172
≥100 USD $2.757568
≥500 USD $2.389992
≥1000 USD $2.267478
≥3000 USD $2.034595
Inventory: 3065
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulse Width Distortion (Max) 4.9ns
Isolated Power No
Inputs - Side 1/Side 2 3/1
Common Mode Transient Immunity (Min) 85kV/μs
Propagation Delay tpLH / tpHL (Max) 16.5ns, 16.5ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.4ns 2.4ns
Data Rate 100Mbps
Number of Channels 4
Voltage - Isolation 5000Vrms
JESD-30 Code R-PDSO-G16
Base Part Number ISO7741
Supply Voltage 2.5V
Number of Functions 4
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology Capacitive Coupling
Additional Feature ALSO REQUIRE VCC2 FROM 2..2-5.5V; ALSO OPERATE WITH 3.3V AND 5 V SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
