ISO7731FQDBQQ1

Texas Instruments
RoHS
RoHS RoHS compliant
Package 16-SSOP (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description 16-SSOP (0.154 3.90mm Width) 3 2/1 General Purpose Digital Isolator 85kV/mus 3000Vrms 100Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $2.65
Unit Price: USD $2.6488
≥1 USD $2.6488
≥10 USD $2.37952
≥100 USD $2.249746
≥500 USD $1.94979
≥1000 USD $1.849822
≥3000 USD $1.65983
Inventory: 770
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length 4.905mm
Height Seated (Max) 1.75mm

Technical

Pulse Width Distortion (Max) 4.9ns
Isolated Power No
Inputs - Side 1/Side 2 2/1
Common Mode Transient Immunity (Min) 85kV/μs
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 1.3ns 1.4ns
Data Rate 100Mbps
Number of Channels 3
Voltage - Isolation 3000Vrms
JESD-30 Code R-PDSO-G16
Base Part Number ISO7731
Supply Voltage 2.5V
Number of Functions 3
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology Capacitive Coupling
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Operating Temperature -40°C~125°C

Physical

Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 6 Weeks
