ISO7721QDQ1

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description 8-SOIC (0.154 3.90mm Width) 2 1/1 General Purpose Digital Isolator 85kV/mus 3000Vrms 100Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 129449
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)

Physical

Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8

Technical

Operating Temperature -40°C~125°C
Packaging Tube
Series Automotive, AEC-Q100
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2
Number of Terminations 8
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology Capacitive Coupling
Voltage - Supply 2.25V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Supply Voltage 2.5V
Base Part Number ISO7721
Voltage - Isolation 3000Vrms
Number of Channels 2
Data Rate 100Mbps
Rise / Fall Time (Typ) 3.9ns 3.9ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Common Mode Transient Immunity (Min) 85kV/μs
Inputs - Side 1/Side 2 1/1
Isolated Power No
Pulse Width Distortion (Max) 4.9ns

Dimensions

Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm

Compliance

RoHS Status ROHS3 Compliant
