ISO7721BDWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGT ISOL 5000VRMS 2CH CAN 16SOIC
PDF
/
Buying Options
Total Price: USD $2.2
Unit Price: USD $2.2
≥1 USD $2.2
≥10 USD $1.97824
≥100 USD $1.866304
≥500 USD $1.590248
≥1000 USD $1.493184
≥3000 USD $1.306536
Inventory: 1532
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
Type CAN, RS232, RS485
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology Capacitive Coupling
Voltage - Supply 2.25V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 3.3V
Base Part Number ISO7721
JESD-30 Code R-PDSO-G16
Voltage - Isolation 5000Vrms
Number of Channels 2
Data Rate 100Mbps
Rise / Fall Time (Typ) 1.8ns 1.9ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 16ns, 16ns
Common Mode Transient Immunity (Min) 85kV/μs
Inputs - Side 1/Side 2 1/1
Isolated Power No
Pulse Width Distortion (Max) 4.9ns
Dimensions
Length 10.3mm
Compliance
RoHS Status ROHS3 Compliant
