ISO7521CDW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 4.243KV GEN PURP 16SOIC
PDF
/
Buying Options
Total Price: USD $3.76
Unit Price: USD $3.7576
≥1 USD $3.7576
≥10 USD $3.37392
≥100 USD $3.18978
≥500 USD $2.76437
≥1000 USD $2.62262
≥3000 USD $2.35327
Inventory: 280
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 16
Weight 547.485991mg
Technical
Operating Temperature -40°C~105°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
ECCN Code EAR99
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Power Dissipation 42mW
Technology Capacitive Coupling
Voltage - Supply 3.15V~3.45V 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 3.3V
Depth 38mm
Base Part Number ISO7521
Pin Count 16
Voltage - Isolation 4243Vrms
Polarity Bidirectional
Number of Channels 2
Operating Supply Current 2mA
Propagation Delay 14 ns
Turn On Delay Time 9 ns
Data Rate 1Mbps
Rise Time 1 ns
Rise / Fall Time (Typ) 1ns, 1ns
Max Input Current 10μA
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 14ns, 14ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 1/1
Isolated Power No
Pulse Width Distortion (PWD) 3.7 ns
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
