ISO7420MD
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
TEXAS INSTRUMENTS ISO7420MD Digital Isolator, Dual, 2 Channel, 12 ns, 3 V, 5.5 V, SOIC, 8 Pins
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.0216
≥1 USD $4.0216
≥10 USD $3.61328
≥100 USD $3.415694
≥500 USD $2.960258
≥1000 USD $2.808432
≥3000 USD $2.520003
Inventory: 1128
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 540.001716mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Power Dissipation 390mW
Technology Capacitive Coupling
Voltage - Supply 3.15V~3.45V 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 2
Supply Voltage 3.3V
Depth 1.5mm
Base Part Number ISO7420
Voltage - Isolation 2500Vrms
Number of Channels 2
Operating Supply Current 400μA
Nominal Supply Current 20mA
Propagation Delay 15 ns
Turn On Delay Time 15 ns
Data Rate 1Mbps
Rise Time 2ns
Rise / Fall Time (Typ) 1ns 1ns
Max Input Current 10μA
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 14ns, 14ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 2/0
Isolated Power No
Pulse Width Distortion (PWD) 3.7 ns
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
