ISO7342FCDWR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description Quad Channel Digital Isolators 16-Pin SOIC T/R
PDF
/
Buying Options
Total Price: USD $4.29
Unit Price: USD $4.2944
≥1 USD $4.2944
≥10 USD $3.8544
≥100 USD $3.643552
≥500 USD $3.157792
≥1000 USD $2.995872
≥3000 USD $2.688189
Inventory: 4104
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
Type General Purpose
Additional Feature IT ALSO OPERATES AT 5 V
Technology Capacitive Coupling
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Base Part Number ISO7342
Voltage - Isolation 3000Vrms
Number of Channels 4
Data Rate 25Mbps
Rise / Fall Time (Typ) 2.1ns 1.7ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 58ns, 58ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 2/2
Isolated Power No
Pulse Width Distortion (Max) 4.1ns

Dimensions

Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
