ISO7342CDWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 3KV 4CH GEN PURP 16SOIC
PDF
/
Buying Options
Total Price: USD $4.29
Unit Price: USD $4.2944
≥1 USD $4.2944
≥10 USD $3.8544
≥100 USD $3.643552
≥500 USD $3.157792
≥1000 USD $2.995872
≥3000 USD $2.688189
Inventory: 1026
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature IT ALSO OPERATES AT 5 V
Technology Capacitive Coupling
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Base Part Number ISO7342
Voltage - Isolation 3000Vrms
Number of Channels 4
Propagation Delay 58 ns
Data Rate 25Mbps
Rise / Fall Time (Typ) 2.1ns 1.7ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 58ns, 58ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 2/2
Isolated Power No
Pulse Width Distortion (PWD) 4 ns
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
