ISO7330CQDWQ1
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
16-SOIC (0.295 7.50mm Width) 3 3/0 General Purpose Digital Isolator 25kV/mus 3000Vrms 25Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7127
≥1 USD $6.7127
≥10 USD $5.5081
≥100 USD $5.3352
≥500 USD $5.16325
≥1000 USD $4.9913
Inventory: 521
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (Max) 4ns
Isolated Power No
Inputs - Side 1/Side 2 3/0
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 58ns, 58ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 3ns 2ns
Data Rate 25Mbps
Number of Channels 3
Voltage - Isolation 3000Vrms
Base Part Number ISO7330
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 3
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Additional Feature IT ALSO OPERATES AT 5 V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 12 Weeks
