ISO7310CQDQ1
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 3KV 1CH GEN PURP 8SOIC
PDF
/
Buying Options
Total Price: USD $34.13
Unit Price: USD $34.1316
≥1 USD $34.1316
≥10 USD $28.006
≥100 USD $27.1301
≥500 USD $26.25515
≥1000 USD $25.3802
Inventory: 3642
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Pulse Width Distortion (Max) 4ns
Isolated Power No
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 58ns, 58ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2ns
Data Rate 25Mbps
Number of Channels 1
Voltage - Isolation 3000Vrms
Base Part Number ISO7310
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Additional Feature IT ALSO OPERATES AT 5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series Automotive, AEC-Q100
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 12 Weeks
