ISO7310CDR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
Digital Isolator 8-Pin SOIC T/R
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.3848
≥1 USD $2.3848
≥10 USD $2.14544
≥100 USD $2.024352
≥500 USD $1.724624
≥1000 USD $1.619411
≥3000 USD $1.416976
Inventory: 1421
Minimum: 1
-
+
Technical Details
Technical
Isolated Power No
Pulse Width Distortion (PWD) 4 ns
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 58ns, 58ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2ns
Data Rate 25Mbps
Propagation Delay 58 ns
Number of Channels 1
Voltage - Isolation 3000Vrms
Base Part Number ISO7310
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
