ISO7241CDWRG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 2500VRMS 4CH GP 16SOIC
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.88005
≥1 USD $1.88005
≥10 USD $1.5428
≥100 USD $1.49435
≥500 USD $1.4459
≥1000 USD $1.39745
Inventory: 66831
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (Max) 2.5ns
Isolated Power No
Inputs - Side 1/Side 2 3/1
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2ns 2ns
Data Rate 25Mbps
Turn On Delay Time 95 ns
Propagation Delay 56 ns
Number of Channels 4
Voltage - Isolation 2500Vrms
Pin Count 16
Base Part Number ISO7241
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.15V~5.5V
Technology Capacitive Coupling
Additional Feature ALSO REQUIRES 3.15V TO 5.5V VCC2 SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Weight 420.395078mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 12 Weeks
