Category Isolators / Digital Isolators
Description
DGTL ISO 2500VRMS 4CH GP 16SOIC
PDF
/
Buying Options
Total Price: USD $11.17
Unit Price: USD $11.170153
≥1 USD $11.170153
≥200 USD $4.457296
≥480 USD $4.308938
≥1000 USD $4.235415
Inventory: 1535
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Pulse Width Distortion (PWD) 2.5 ns
Isolated Power No
Inputs - Side 1/Side 2 4/0
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Channel Type Unidirectional
Max Input Current 10μA
Rise / Fall Time (Typ) 2ns, 2ns
Rise Time 2 ns
Data Rate 25Mbps
Turn On Delay Time 18 ns
Propagation Delay 95 ns
Power Dissipation 220mW
Nominal Supply Current 15mA
Number of Channels 4
Voltage - Isolation 2500Vrms
Pin Count 16
Base Part Number ISO7240
Depth 10.63mm
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.15V~5.5V
Technology Capacitive Coupling
Additional Feature ALSO REQUIRES 3.15V TO 5.5V VCC2 SUPPLY
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 420.395078mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 12 Weeks
Alternative Model
