ISO722DRG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description DGTL ISO 2500VRMS 1CH GP 8SOIC
PDF
/
Buying Options
Total Price: USD $33.18
Unit Price: USD $33.1797
≥1 USD $33.1797
≥10 USD $27.22415
≥100 USD $26.3739
≥500 USD $25.5227
≥1000 USD $24.67245
Inventory: 1336
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 75.891673mg

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology Capacitive Coupling
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Base Part Number ISO722
Pin Count 8
Voltage - Isolation 2500Vrms
Number of Channels 1
Nominal Supply Current 10mA
Power Dissipation 159mW
Propagation Delay 24 ns
Turn On Delay Time 34 ns
Data Rate 100Mbps
Rise / Fall Time (Typ) 1ns 1ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 24ns, 24ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 1/0
Isolated Power No
Pulse Width Distortion (PWD) 2 ns

Dimensions

Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
