ISO7221BDG4

Texas Instruments
RoHS
/
Package SOIC
Category Isolators / Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 8SOIC
PDF
/
Inventory: 6638
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 4.9mm
Height Seated (Max) 1.75mm

Technical

Pulse Width Distortion (PWD) 3 ns
Channel Type Unidirectional
Data Rate 5 Mbps
Propagation Delay 70 ns
Nominal Supply Current 8.5mA
Min Supply Voltage 3.3V
Max Supply Voltage 5V
Number of Channels 2
Temperature Grade AUTOMOTIVE
Voltage - Isolation 4kV
Pin Count 8
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish NICKEL PALLADIUM GOLD
Type General Purpose
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4

Physical

Number of Pins 8
Surface Mount YES
Package / Case SOIC
