ISO7221ADR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
TEXAS INSTRUMENTS ISO7221ADR DIGITAL ISOLATOR, 475NS, SOIC-8
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.90898
≥1 USD $0.90898
≥10 USD $0.85753
≥100 USD $0.80899
≥500 USD $0.7632
≥1000 USD $0.72
≥3000 USD $0.67925
Inventory: 10241
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 540.001716mg
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type General Purpose
Technology Capacitive Coupling
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Base Part Number ISO7221
Pin Count 8
Voltage - Isolation 2500Vrms
Operating Supply Voltage 5V
Number of Channels 2
Nominal Supply Current 10mA
Propagation Delay 475 ns
Turn On Delay Time 475 ns
Data Rate 1Mbps
Rise / Fall Time (Typ) 1ns, 1ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 475ns, 475ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 1/1
Isolated Power No
Pulse Width Distortion (PWD) 14 ns
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
