ISO7221ADG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description DGTL ISO 2500VRMS 2CH GP 8SOIC
PDF
/
Buying Options
Total Price: USD $2.81
Unit Price: USD $2.809088
≥1 USD $2.809088
≥10 USD $2.650082
≥100 USD $2.500082
≥500 USD $2.358568
≥1000 USD $2.225058
Inventory: 1388
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm

Technical

Pulse Width Distortion (PWD) 14 ns
Isolated Power No
Inputs - Side 1/Side 2 1/1
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 475ns, 475ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 1ns 1ns
Data Rate 1Mbps
Propagation Delay 475 ns
Nominal Supply Current 85mA
Number of Channels 2
Voltage - Isolation 2500Vrms
Pin Count 8
Base Part Number ISO7221
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type General Purpose
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C

Physical

Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 12 Weeks
