ISO721D
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
TEXAS INSTRUMENTS - ISO721D - DIGITAL ISOLATOR, 24NS, SOIC-8
PDF
/
Buying Options
Total Price: USD $5.43
Unit Price: USD $5.4296
≥1 USD $5.4296
≥10 USD $4.88048
≥100 USD $4.61355
≥500 USD $3.99843
≥1000 USD $3.793354
≥3000 USD $3.40377
Inventory: 5100
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Pulse Width Distortion (PWD) 2 ns
Isolated Power No
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 24ns, 24ns
Channel Type Unidirectional
Max Input Current 10μA
Rise / Fall Time (Typ) 1ns, 1ns
Rise Time 2 ns
Data Rate 100Mbps
Turn On Delay Time 24 ns
Propagation Delay 24 ns
Output Current 4mA
Nominal Supply Current 10mA
Number of Channels 1
Voltage - Isolation 2500Vrms
Pin Count 8
Base Part Number ISO721
Depth 1.75mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Additional Feature ALSO OPERATES FROM 4.5 TO 5.5 V SUPPLY
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 75.891673mg
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 12 Weeks
