ISO7131CCDBQ
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 2500VRMS 3CH GP 16SSOP
PDF
/
Buying Options
Total Price: USD $5.03
Unit Price: USD $5.0336
≥1 USD $5.0336
≥10 USD $4.52056
≥100 USD $4.273518
≥500 USD $3.703744
≥1000 USD $3.51384
≥3000 USD $3.152952
Inventory: 429
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.5mm
Width 3.9mm
Length 4.9mm
Height 1.75mm
Technical
Pulse Width Distortion (PWD) 3 ns
Isolated Power No
Inputs - Side 1/Side 2 2/1
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 35ns, 35ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2ns, 2ns
Data Rate 50Mbps
Propagation Delay 23 ns
Power Dissipation 150mW
Nominal Supply Current 10.5mA
Number of Channels 3
Voltage - Isolation 2500Vrms
Base Part Number ISO7131
Supply Voltage 3.3V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology Capacitive Coupling
Max Power Dissipation 150mW
Additional Feature ALSO OPERATES WITH 5 V SUPPLY
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 16
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 12 Weeks
Alternative Model
