ISO7041DBQR
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
16-SSOP (0.154 3.90mm Width) 4 3/1 SPI Digital Isolator 50kV/mus 3000Vrms 2Mbps -55C~125C
PDF
/
Buying Options
Total Price: USD $17.45
Unit Price: USD $17.4515
≥1 USD $17.4515
≥10 USD $14.31935
≥100 USD $13.8719
≥500 USD $13.42445
≥1000 USD $12.977
Inventory: 1527
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SSOP (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
Type SPI
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature ALSO OPERATES WITH 3.3V AND 5V SUPPLY
Technology Capacitive Coupling
Voltage - Supply 2.25V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 4
Supply Voltage 3.3V
Terminal Pitch 0.635mm
Base Part Number ISO7041
JESD-30 Code R-PDSO-G16
Voltage - Isolation 3000Vrms
Number of Channels 4
Data Rate 2Mbps
Rise / Fall Time (Typ) 5ns 5ns Max
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 165ns, 165ns
Common Mode Transient Immunity (Min) 50kV/μs
Inputs - Side 1/Side 2 3/1
Isolated Power No
Pulse Width Distortion (Max) 10ns
Dimensions
Height Seated (Max) 1.75mm
Compliance
RoHS Status ROHS3 Compliant
