ISO3080DWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 4KV RS422/RS485 16SOIC
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $4.004
≥1 USD $4.004
≥10 USD $3.59832
≥100 USD $3.40208
≥500 USD $2.94844
≥1000 USD $2.797238
≥3000 USD $2.662
Inventory: 1564
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Isolated Power No
Output Low Current-Max 0.008A
Inputs - Side 1/Side 2 2/1
Supply Voltage1-Nom 5V
Common Mode Transient Immunity (Min) 25kV/μs
Simplex/Duplex Full Duplex
Number of Output Lines 1
ESD Protection Yes
Interface Standard EIA-422; TIA-422; EIA-485; TIA-485
Receiver Number of Bits 1
Channel Type Unidirectional
Driver Number of Bits 1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Output Polarity COMPLEMENTARY
Differential Output YES
Output Characteristics DIFFERENTIAL
Data Rate 200kbps
Logic Function Receiver
Propagation Delay 700 ns
Max Supply Current 15mA
Nominal Supply Current 10mA
Number of Channels 3
Working Voltage 560V
Voltage - Isolation 2500Vrms
Pin Count 16
Base Part Number ISO3080
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.15V~5.5V 4.5V~5.5V
Technology Capacitive Coupling
Type RS422, RS485
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 12 Weeks
