ISO15DWR
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 4KV RS422/RS485 16SOIC
PDF
/
Buying Options
Total Price: USD $5.93
Unit Price: USD $5.9312
≥1 USD $5.9312
≥10 USD $5.36008
≥100 USD $5.110688
≥500 USD $4.437664
≥1000 USD $4.238256
≥3000 USD $3.864274
Inventory: 1366
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Type RS422, RS485
Subcategory Line Driver or Receivers
Technology Capacitive Coupling
Voltage - Supply 3.15V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Base Part Number ISO15
Pin Count 16
Voltage - Isolation 2500Vrms
Working Voltage 560V
Number of Channels 3
Nominal Supply Current 19mA
Logic Function Transceiver
Data Rate 1Mbps
Differential Output YES
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Max Dual Supply Voltage 3.6V
Driver Number of Bits 1
Min Dual Supply Voltage 3.15V
Dual Supply Voltage 3.3V
Channel Type Unidirectional
Receiver Number of Bits 1
Interface Standard EIA-422; TIA-422; EIA-485; TIA-485
ESD Protection Yes
Number of Output Lines 1
Simplex/Duplex Half Duplex
Common Mode Transient Immunity (Min) 25kV/μs
Supply Voltage1-Nom 3.3V
Inputs - Side 1/Side 2 2/1
Isolated Power No
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
