SI88243BC-ISR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
20-SOIC (0.295 7.50mm Width) 4 1/3 General Purpose Digital Isolator 40kV/mus 5000Vrms 100Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $11.04
Unit Price: USD $11.03755
≥1 USD $11.03755
≥200 USD $4.40478
≥500 USD $4.257735
≥1250 USD $4.184212
Inventory: 9542
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Pulse Width Distortion (Max) 7ns
Isolated Power No
Inputs - Side 1/Side 2 1/3
Common Mode Transient Immunity (Min) 40kV/μs
Propagation Delay tpLH / tpHL (Max) 18ns, 23ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2.5ns
Data Rate 100Mbps
Number of Channels 4
Voltage - Isolation 5000Vrms
Peak Reflow Temperature (Cel) 260
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Type General Purpose
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
