SI8736BC-IS
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
8-SOIC (0.154 3.90mm Width) 1 1/0 General Purpose Digital Isolator 25kV/mus (Typ) 2500Vrms 15Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $1.51
Unit Price: USD $1.5136
≥1 USD $1.5136
≥10 USD $1.35784
≥100 USD $1.091288
≥500 USD $1.024681
≥1000 USD $0.902
Inventory: 111
Minimum: 1
-
+
Technical Details
Technical
Pulse Width Distortion (Max) 25ns
Isolated Power No
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Propagation Delay tpLH / tpHL (Max) 50ns, 50ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2.5ns
Data Rate 15Mbps
Number of Channels 1
Voltage - Isolation 2500Vrms
Voltage - Supply 2.5V~5.5V
Technology Capacitive Coupling
Type General Purpose
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Operating Temperature -40°C~125°C
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
