SI8717BC-A-ISR
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
8-SOIC (0.154 3.90mm Width) 1 1/0 General Purpose Digital Isolator 35kV/mus 3750Vrms 15Mbps 1.7mA
PDF
/
Buying Options
Total Price: USD $2.47
Unit Price: USD $2.469565
≥1 USD $2.469565
≥200 USD $0.985988
≥500 USD $0.953165
≥1000 USD $0.936098
Inventory: 6515
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Pulse Width Distortion (PWD) 25 ns
Isolated Power No
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 35kV/μs
Propagation Delay tpLH / tpHL (Max) 50ns, 50ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2.5ns
Data Rate 15Mbps
Propagation Delay 50 ns
Operating Supply Current 1.7mA
Number of Channels 1
Voltage - Isolation 3750Vrms
Voltage - Supply 2.5V~5.5V
Technology Capacitive Coupling
Max Power Dissipation 253mW
Type General Purpose
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Weight 95.396145mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
