SI8711CD-B-IMR
RoHS
/
Package 8-VELGA
Category Isolators / Digital Isolators
Description
8-VELGA 1 1/0 General Purpose Digital Isolator 20kV/mus 5000Vrms 1Mbps 1.7mA
PDF
/
Inventory: 2801
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 8-VELGA
Surface Mount YES
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 1997
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Type General Purpose
Subcategory Other Analog ICs
Max Power Dissipation 140mW
Technology Capacitive Coupling
Voltage - Supply 3V~30V
Terminal Position DUAL
Supply Voltage 5V
Terminal Pitch 2.54mm
Voltage - Isolation 5000Vrms
Power Supplies 5V
Number of Channels 1
Operating Supply Current 1.7mA
Propagation Delay 60 ns
Turn On Delay Time 30 ns
Data Rate 1Mbps
Rise / Fall Time (Typ) 15ns 5ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 60ns, 60ns
Common Mode Transient Immunity (Min) 20kV/μs
Inputs - Side 1/Side 2 1/0
Isolated Power No
Pulse Width Distortion (PWD) 20 ns
Compliance
RoHS Status RoHS Compliant
