SI8660EC-B-IS1
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 3750VRMS 6CH GP 16SOIC
PDF
/
Buying Options
Total Price: USD $3.59
Unit Price: USD $3.5904
≥1 USD $3.5904
≥10 USD $3.22696
≥100 USD $3.05067
≥500 USD $2.643854
≥1000 USD $2.508246
≥3000 USD $2.387
Inventory: 20585
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 3.9mm
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Pulse Width Distortion (PWD) 4.5 ns
Isolated Power No
Inputs - Side 1/Side 2 6/0
Common Mode Transient Immunity (Min) 35kV/μs
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Channel Type Unidirectional
Max Input Current 12.3mA
Rise / Fall Time (Typ) 2.5ns, 2.5ns
Rise Time 4 ns
Data Rate 150Mbps
Turn On Delay Time 10 ns
Propagation Delay 13 ns
Power Dissipation 415mW
Nominal Supply Current 18.3mA
Number of Channels 6
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 2.5/5V
Supply Voltage-Max (Vsup) 5.5V
Voltage - Isolation 3750Vrms
Pin Count 16
Time@Peak Reflow Temperature-Max (s) 40
Depth 1.25mm
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology Capacitive Coupling
Subcategory Other Analog ICs
HTS Code 8542.39.00.01
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Pbfree Code yes
Published 1997
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 50.008559mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
