SI8642BB-B-IS
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
Low Power Quad Channel Digital Isolator 16-Pin SOIC W
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.5552
≥1 USD $3.5552
≥10 USD $3.1944
≥100 USD $3.019738
≥500 USD $2.617041
≥1000 USD $2.482876
≥3000 USD $2.227861
Inventory: 918
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2000
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 16
Type General Purpose
Max Power Dissipation 275mW
Technology Capacitive Coupling
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Depth 1.25mm
Voltage - Isolation 2500Vrms
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.5V
Number of Channels 4
Operating Supply Current 3.6mA
Propagation Delay 13 ns
Data Rate 150Mbps
Rise Time 4ns
Rise / Fall Time (Typ) 2.5ns 2.5ns
Max Input Current 6.6mA
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Common Mode Transient Immunity (Min) 35kV/μs
Inputs - Side 1/Side 2 2/2
Isolated Power No
Pulse Width Distortion (PWD) 4.5 ns
Dimensions
Height Seated (Max) 2.65mm
Length 9.9mm
Width 3.9mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
