SI8600AB-B-IS
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
I2C tal Isolator 2500Vrms 2 Channel 35kV/μs CMTI 8-SOIC (0.154 , 3.90mm Width)
PDF
/
Buying Options
Total Price: USD $5.77
Unit Price: USD $5.7728
≥1 USD $5.7728
≥10 USD $5.21664
≥100 USD $4.319058
≥500 USD $4.124912
≥1000 USD $3.760962
≥3000 USD $3.275677
Inventory: 371
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 1997
Part Status Active
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Number of Terminations 8
Type I2C
Max Power Dissipation 220mW
Technology Capacitive Coupling
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 3.3V
Depth 1.5mm
Voltage - Isolation 2500Vrms
Number of Channels 2
Operating Supply Current 5.4mA
Propagation Delay 44 ns
Data Rate 10 Mbps
Rise Time 4ns
Screening Level AEC-Q100
Max Input Current 7.6mA
Channel Type Bidirectional
Common Mode Transient Immunity (Min) 35kV/μs
Inputs - Side 1/Side 2 2/2
Isolated Power No
Dimensions
Length 5mm
Width 4mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
