SI8441BB-C-IS1
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 2500VRMS 4CH GP 16SOIC
PDF
/
Buying Options
Total Price: USD $11.26
Unit Price: USD $11.256805
≥1 USD $11.256805
≥192 USD $4.491431
≥480 USD $4.34176
≥1008 USD $4.266925
Inventory: 2526
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Pulse Width Distortion (PWD) 2.5 ns
Isolated Power No
Inputs - Side 1/Side 2 3/1
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Propagation Delay tpLH / tpHL (Max) 9.5ns, 9.5ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 3.8ns 2.8ns
Data Rate 150Mbps
Turn On Delay Time 9.5 ns
Propagation Delay 9.5 ns
Power Dissipation 275mW
Nominal Supply Current 4.9mA
Number of Channels 4
Voltage - Isolation 2500Vrms
Pin Count 16
Terminal Pitch 1.27mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology Capacitive Coupling
Terminal Finish Matte Tin (Sn)
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Not For New Designs
JESD-609 Code e3
Published 2000
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 188.155785mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
