SI8440BA-D-IS1
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 1KV 4CH GEN PURP 16SOIC
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.735583
≥1 USD $10.735583
≥192 USD $4.283993
≥480 USD $4.140887
≥1008 USD $4.06999
Inventory: 5753
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 16
Weight 188.155785mg
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2000
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
Type General Purpose
Technology Capacitive Coupling
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Terminal Pitch 1.27mm
Pin Count 16
Voltage - Isolation 1000Vrms
Number of Channels 4
Operating Supply Current 6mA
Propagation Delay 9.5 ns
Turn On Delay Time 9.5 ns
Data Rate 150Mbps
Rise / Fall Time (Typ) 3.8ns 2.8ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 9.5ns, 9.5ns
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Inputs - Side 1/Side 2 4/0
Isolated Power No
Pulse Width Distortion (PWD) 2.5 ns
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Compliance
RoHS Status RoHS Compliant
