SI8440AB-C-IS
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
Digital Isolator CMOS 4-CH 1Mbps 16-Pin SOIC W
PDF
/
Buying Options
Total Price: USD $9.17
Unit Price: USD $9.171919
≥1 USD $9.171919
≥184 USD $3.660365
≥506 USD $3.538266
≥1012 USD $3.477872
Inventory: 9390
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 7.5mm
Length 10.3mm
Height Seated (Max) 2.65mm
Technical
Channel Type Unidirectional
Interface IC Type INTERFACE CIRCUIT
Data Rate 1Mbps
Turn On Delay Time 35 ns
Propagation Delay 35 ns
Power Dissipation 275mW
Nominal Supply Current 5.7mA
Number of Channels 4
Qualification Status Not Qualified
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology CMOS
Terminal Finish MATTE TIN
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Not For New Designs
JESD-609 Code e3
Series ISOpro
Published 2012
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 547.51434mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
