SI8405AA-A-IS1
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGT ISOL 1000VRMS 4CH I2C 16SOIC
PDF
/
Buying Options
Total Price: USD $9.18
Unit Price: USD $9.177171
≥1 USD $9.177171
≥192 USD $3.662991
≥480 USD $3.539578
≥1008 USD $3.479185
Inventory: 9526
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Isolated Power No
Inputs - Side 1/Side 2 3/3
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Channel Type Bidirectional, Unidirectional
Data Rate 1.7 Mbps
Propagation Delay 40 ns
Power Dissipation 275W
Nominal Supply Current 3.2mA
Number of Channels 4
Voltage - Isolation 1000Vrms
Pin Count 16
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Type I2C
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Published 1997
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Weight 188.155785mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
