ISO150AU
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width), 12 Leads
Category Isolators / Digital Isolators
Description
28-SOIC (0.295 7.50mm Width) 12Leads 2 2/2 General Purpose Digital Isolator 1.6kV/mus (Typ) 1500Vrms 80MBd -40C~85C
PDF
/
Buying Options
Total Price: USD $11.06
Unit Price: USD $11.0599
≥1 USD $11.0599
≥10 USD $9.07535
≥100 USD $8.7913
≥500 USD $8.5082
≥1000 USD $8.22415
Inventory: 2187
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulse Width Distortion (Max) 6ns
Isolated Power No
Inputs - Side 1/Side 2 2/2
Common Mode Transient Immunity (Min) 1.6kV/μs (Typ)
Propagation Delay tpLH / tpHL (Max) 40ns, 40ns
Channel Type Bidirectional
Rise / Fall Time (Typ) 9ns 9ns
Data Rate 80MBd
Number of Channels 2
Voltage - Isolation 1500Vrms
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
Type General Purpose
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Supplier Device Package 12-SOP
Package / Case 28-SOIC (0.295, 7.50mm Width), 12 Leads
Mounting Type Surface Mount
