AD261AND-1 image
Favorite
AD261AND-1 image
Favorite
RoHS
/
Package 22-DIP Module
Category Isolators / Digital Isolators
Description 22-DIP Module 5 1/4 General Purpose Digital Isolator 10kV/mus 1750Vrms -25C~85C 5V
PDF
/
Buying Options
Total Price: USD $156.81
Unit Price: USD $156.81015
≥1 USD $156.81015
≥200 USD $62.568875
≥500 USD $60.477426
≥1000 USD $59.445486
Inventory: 4119
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Through Hole
Package / Case 22-DIP Module
Surface Mount NO

Technical

Operating Temperature -25°C~85°C
Packaging Tube
Series IsoLogic?
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Type General Purpose
Technology Magnetic Coupling
Voltage - Supply 4V~5.75V
Terminal Position QUAD
Supply Voltage 5V
Pin Count 22/16
JESD-30 Code R-PQIP-T16
Qualification Status COMMERCIAL
Voltage - Isolation 1750Vrms
Number of Channels 5
Number of I/O 5
Number of Ports 1
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 25ns, 25ns
Common Mode Transient Immunity (Min) 10kV/μs
Inputs - Side 1/Side 2 1/4
Isolated Power No

Dimensions

Height Seated (Max) 11.18mm
Width 11.43mm

Compliance

RoHS Status Non-RoHS Compliant
