IL 612A-2 image
Favorite
IL 612A-2 image
Favorite
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Isolators / Digital Isolators
Description 8-DIP (0.300 7.62mm) 2 1/1 General Purpose Digital Isolator 15kV/mus 2500Vrms 10Mbps -55C~125C
PDF
/
Inventory: 5685
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Length 9.6mm
Height Seated (Max) 4.7mm

Technical

Isolated Power No
Inputs - Side 1/Side 2 1/1
Common Mode Transient Immunity (Min) 15kV/μs
Propagation Delay tpLH / tpHL (Max) 75ns, 25ns
Channel Type Unidirectional
Data Rate 10Mbps
Number of Channels 2
Voltage - Isolation 2500Vrms
JESD-30 Code R-PDIP-T8
Pin Count 8
Supply Voltage 3.3V
Number of Functions 2
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology GMR (Giant Magnetoresistive)
Type General Purpose
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series IsoLoop?
Packaging Tube
Operating Temperature -55°C~125°C

Physical

Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
