MAX14939GWE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
16-SOIC (0.295 7.50mm Width) 3 2/1 RS485 Digital Isolator 35kV/mus (Typ) 2750Vrms 20Mbps -40C~105C
PDF
/
Buying Options
Total Price: USD $9.46
Unit Price: USD $9.46
≥1 USD $9.46
≥10 USD $8.69704
≥100 USD $8.336469
≥500 USD $7.345131
≥1000 USD $6.984648
≥3000 USD $6.534018
Inventory: 137
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Isolated Power No
Inputs - Side 1/Side 2 2/1
Common Mode Transient Immunity (Min) 35kV/μs (Typ)
Propagation Delay tpLH / tpHL (Max) 68ns, 68ns
Number of Drivers 1
Channel Type Unidirectional
Rise / Fall Time (Typ) 15ns 15ns Max
Data Rate 20Mbps
Interface RS-485
Number of Channels 3
Voltage - Isolation 2750Vrms
Base Part Number MAX14939
Voltage - Supply 1.71V~5.5V 4.5V~5.5V
Technology Capacitive Coupling
Type RS485
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2016
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
