MAX14932EASE+T
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 2750VRMS 4CH GP 16SOIC
PDF
/
Buying Options
Total Price: USD $6.53
Unit Price: USD $6.530365
≥1 USD $6.530365
≥200 USD $2.606107
≥500 USD $2.519455
≥1000 USD $2.476129
Inventory: 8989
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulse Width Distortion (Max) 2.6ns
Isolated Power No
Inputs - Side 1/Side 2 2/2
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Propagation Delay tpLH / tpHL (Max) 27.5ns, 28.8ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2ns 2ns
Data Rate 25Mbps
Number of Channels 4
Voltage - Isolation 2750Vrms
Base Part Number MAX14932
Voltage - Supply 1.71V~5.5V
Technology Capacitive Coupling
Type General Purpose
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
