MAX14932BAWE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 2750VRMS 4CH GP 16SOIC
PDF
/
Buying Options
Total Price: USD $5.7
Unit Price: USD $5.7024
≥1 USD $5.7024
≥10 USD $5.11896
≥100 USD $4.839428
≥500 USD $4.194221
≥1000 USD $3.979166
≥3000 USD $3.570486
Inventory: 36
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulse Width Distortion (Max) 2.6ns
Isolated Power No
Inputs - Side 1/Side 2 2/2
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Propagation Delay tpLH / tpHL (Max) 27.5ns, 28.8ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2ns 2ns
Data Rate 25Mbps
Number of Channels 4
Supply Voltage-Min (Vsup) 1.71V
Supply Voltage-Max (Vsup) 5.5V
Voltage - Isolation 2750Vrms
JESD-30 Code R-PDSO-G16
Base Part Number MAX14932
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.71V~5.5V
Technology Capacitive Coupling
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2016
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
